How to Setup a Mirrored Array in Windows 2012

This is a software RAID Level 1 in Windows 2012, which means that two or more disks are holding the exact same data.

The hard drives are constantly kept in sync in real time, in case one of the disks fails, Mirroring is not a backup solution. In my tutorial I’m using 2 Unallocated/unformatted 50 GB hard drives. The same process applies to larger HDD’s.

1. Go to Server Manager select Tools and click on Computer Management from the drop down menu.

How to set up a Mirrored Array in Windows 2012 1

2. Then select Disk Management

How to set up a Mirrored Array in Windows 2012 2

3. Now notice that Disk 1 and Disk 2 are in Unallocated state.

How to set up a Mirrored Array in Windows 2012 3

4. Right click on the Disk 1 or Disk 2 and select New Mirrored Volume… from the drop-down menu.

How to set up a Mirrored Array in Windows 2012 4

5. On the wizard, click Next to continue

How to set up a Mirrored Array in Windows 2012 5

6. Under Available: select the drive or drives you want to hold the mirrored array and click Add. Note: You can add as many drives as you want. Click Next.

How to set up a Mirrored Array in Windows 2012 6

7. Once you select the disk, click add then click on Next button.

How to set up a Mirrored Array in Windows 2012 7

8. Now Assign a drive letter, and then click Next.

How to set up a Mirrored Array in Windows 2012 8

9. Now Select the File system: NTFS, Re-name the Volume label to your choice, then check-mark Perform quick format and then click Next.

How to set up a Mirrored Array in Windows 2012 9

10. Then click Finish to start formatting and Sync the drives.

How to set up a Mirrored Array in Windows 2012 10

11. A warning will pop up telling you that the drives will be converted to dynamic disks. Click Yes

How to set up a Mirrored Array in Windows 2012 11

12. Once done, you can see the mirrored drives as a new Volume (E:) in the Disk management console.

How to set up a Mirrored Array in Windows 2012 12
